Toilet Flush Cistern

When you rinse, the Toilet Flush Cistern must be automatically refilled from a side tap and the refill operation must last long enough to fill the tank without spilling it. Some water is always trapped in a large elbow at the bottom of the toilet, called the S-trap. This little bit of water effectively seals the sewer line below it, preventing bacteria and unpleasant smells from entering your bathroom.

Product classification:PRODUCT
Consult now:+86-1892485-8611/ 8635/ 8981

Product details

Product description

When you rinse, the Toilet Flush Cistern must be automatically refilled from a side tap and the refill operation must last long enough to fill the tank without spilling it. Some water is always trapped in a large elbow at the bottom of the toilet, called the S-trap. This little bit of water effectively seals the sewer line below it, preventing bacteria and unpleasant smells from entering your bathroom. S-bend also means that the pipe coming out of the toilet is bent upwards and then bent down again. This means that as water flows from the tank into the tank and exits through the hose, it has sufficient momentum to create a siphon effect to properly empty the tank. Toilet Flush Cistern is equipped with a water supply pipe through a float valve located in the water tank. At each flush, the float drops to a reduced water level, opening the valve and allowing the tank to refill. When the water level in the Toilet Flush Cistern reaches a preset level, the float valve closes and the flushing system is ready for use again.


Product specifications

Item Code

021B-5

Suit with

Bathroom Squatting Pan

Dimension(mm):

403x97x408mm

Type

Exposed outside; Low level cistern

Tank body color

white

Material

PP

Flush volume

3L and 6L max. 7.5L

Button color

white

Flushing type

Dual flush

Button Type

Top dual triangle button

Entry type

Bottom Entry

Delivery Time

LCL 5-10 days, 20GP and 40HQ need 20-25days

Bend pipe diameter

45mm

Straight pipe diameter

50mm

Squat pan filling hole require

inner φ52-58mm

Wall to squat pan hole distance

200-340mm

Price terms

LCL will be EXW shunde, china; container goods will be FOB shunde, china

Loading port

SHUNDE, CHINA / SHENZHEN, CHINE/ GUANGZHOU, CHINA
