WC Concealed Cistern

This WC Concealed Cistern uses a 110mm high-density polyethylene black flushing elbow, if required to provide a 90mm flush elbow. It uses a standard metal frame and no top beam. It can withstand up to 400kg. Its hose allows for quick water injection and ensures that the tank does not leak. It is equipped with a shut-off valve for easier installation, no leakage and long service life. Its base plate and set screws are very strong, thus ensuring the stability of the frame of the entire product.

Product classification:Normal Concealed Cistern
Consult now:+86-1892485-8611/ 8635/ 8981

Product details

Product description

This WC Concealed Cistern uses a 110mm high-density polyethylene black flushing elbow, if required to provide a 90mm flush elbow. It uses a standard metal frame and no top beam. It can withstand up to 400kg. Its hose allows for quick water injection and ensures that the tank does not leak. It is equipped with a shut-off valve for easier installation, no leakage and long service life. Its base plate and set screws are very strong, thus ensuring the stability of the frame of the entire product. It offers wall-mounted options, so there is no compromise in style and appearance. WC Concealed Cistern offers a bathroom design solution and a fully clear and open floor area. Its compact design makes it ideal for under- or low-wall installations. WC Concealed Cistern offers a dual flush polished chrome control panel so its push plate can be mounted on the front or top of the tank. The water tank is hidden behind the wall and can be maintained through the button panel.

Product specifications:

Dimension(mm)

512x127x1027.5mm

Flush pipe diameter

110mm

Carton Size (mm)

523x150x1110mm

Suit for

Bathroom wall hung toilet

Need wall thickness

≥155mm

Material

HDPE +A metal frame

For wall

dry wall and pre-wall and dry half wall and pre-half wall

Flush volumn

3L/ 6L max. 8L

MOQ

50 PCS

Port of loading

SHUNDE, CHINA / SHENZHEN, CHINE/ GUANGZHOU, CHINA

Package details

1set/ctn; carton packing

Loading qty

0.0871CBM/SET

20GP: 305 sets

40GP: 650 sets

40HQ: 760sets
